Water Agency Gets Unified Platform, Better Reporting, and More

H2O Innovation (H2OI) transformed a 20-year-old SCADA system for Brazos Regional Public Utility Agency (BRPUA), located in Granbury, Texas. This project was the cover story of the July 2018 issue of Water & Wastes Digest.

H2OI turned BRPUA’s antiquated, incohesive SCADA system into a new state-of-the-art Ignition redundant SCADA system. A key part of the project gave BRPUA a much faster, easier way to submit reports to the Texas Commission on Environmental Quality (TCEQ). Other reports were automated as well.

H2O Innovation solved three main problems for BRPUA. The first was the limited number of tags allowed by the legacy SCADA system. Ignition’s unlimited tag model allowed H2OI to include the site’s ultrafiltration (UF) and reverse osmosis (RO) water treatment systems in the SCADA system. Previously, tag limits had excluded these from the SCADA package. BRPUA plans to continue to automate the water treatment plant, so expandability was a key factor in selecting Ignition as the new SCADA platform.

The second major problem was the many non-connected subsystems within the plant’s control network. There was a Wonderware SCADA system that controlled the conventional side of the treatment plant, and there was a UF system supplier PLC and HMI controlling the UF system, and there was an RO system supplier PLC and HMI controlling the RO, and there was a chemical feed system that was also being controlled by the vendor’s PLC. Of the 22 PLCs, only a few were controlled by the SCADA system.

H2OI bridged that gap and created a single source of information and a single point of control. Operators can now go to any of the workstations in the plant and see the same screens. The previous SCADA and control systems required operators to visit several different locations to control different aspects of the plant.

The third and most challenging problem was the old reporting system. The system had to be manually checked, it didn’t pull data in from all of the separate systems, and it didn’t automatically populate the TCEQ document.  H2OI solved all three of these issues. The existing reporting system did not do any verification on the data it was pulling, so if the system was offline, or down for maintenance, the operators would have to manually overwrite the data in the reports so that it wouldn’t be flagged by the governing bodies. Now with the new reporting system, the data is sorted at the database level and is verified by several checks before being validated. This is a huge time savings, as it removes the work associated with double- and triple-checking the reports.

The old reporting system didn’t pull data from all of the subsystems in the plant. For example, operators didn’t have a place to enter data from the lab. The RO and UF systems were segregated from the SCADA system. With the new Ignition interface, operators have one place where they can enter in lab data, pull the UF and RO systems data, and have everything stored into the historian — which can be recalled and reviewed at later dates.

To complete the project, H2O enlisted the help of Automation Station, which is based in South Texas. David Rojas, an automation engineer with Automation Station, worked with H2OI and BRPUA on the reporting aspects of the project.

The automatic generation of the TCEQ report was a huge accomplishment and probably the most important item H2OI was able to contribute. The TCEQ document consists of nine sheets with thousands of fields to populate. H2OI and Automation Station had to work with TCEQ to verify methods and changes to the official document so that data fields could be automatically populated. Since BRPUA is now able to enter the lab data, and can pull data from all subsystems, this data is now available at the database level which can be run through verification tests to validate it. H2OI then pulls all the data into the official Excel document, and with one click of a button can generate the report. This is estimated to save 8-10 operator hours per week. H2OI is really excited about this reporting feature because it can be reused for other potential Texas customers, and would be relatively easy to deploy, now that the code and scripts have been written.

The new Ignition system will also allow BRPUA to give different levels of access to different operators, making it easier to set up the proper security. With this, the phone alerts, and a bit more automation, BRPUA will no longer need to have the facility manned 24 hours per day.
