Project For: DEPCOM Power
Creating the Ultimate SCADA System for Solar Energy
Using Ignition, Vertech developed a SCADA system to monitor and control more than 200MW of utility-scale solar energy production at five plants.
Problem: Solar energy is a growing industry, but utility-scale solar power plants can present many challenges for a traditional SCADA system. A typical solar power plant contains thousands of connected devices from a variety of vendors dispersed across a large geographical area. A robust, scalable SCADA architecture which can be quickly rolled out as new power plants are built requires a lot of forethought. From an operations and maintenance perspective, the amount of data can quickly become overwhelming, clouding the ability to quickly identify and correct any issues. In addition to answering these challenges, Vertech also strives to build a solution which is highly polished, both technically and graphically.
Solution: For its solar power plant SCADA solution, Vertech used the Standard Ignition Architecture including one local historian and one connection to a database in the cloud. On a typical site, the Ignition gateway will be directly connected to nearly 100 devices. However, some of those devices act as gateways themselves, so in total the system is used to monitor and control around 3,000 devices. This amounts to over 15,000 I/O tags per site. This SCADA package is being used at five solar plants, with total generation capability of more than 200MW.
Vertech went to extreme lengths in perfecting the user experience, creating a system which intelligently aggregates data and allows the user to quickly see big-picture information. This applies not only to the graphics in the Vision module, but also to reporting and even Vertech’s own development experience.
For the graphic design, Vertech wanted a framework it could lean on to ensure consistency in color, style, and layout across every component of the application. This morphed into a full implementation of Google’s material design specification in Ignition, resulting in an application which is not only visually appealing but is also intuitive to use. A full graphical theme engine was built on top of the Ignition Vision module to allow each user to select a visual theme of their choosing.
Intelligent reporting, which does more than simply serve up the top 1,000 rows of a database table in a tabular format, is a must on a large solar field. Leveraging the advanced scripting functionality available within the Ignition Reporting module, Vertech designed a report which analyzes the data from the hundreds or thousands of strings of solar panels in order to highlight the lowest performing equipment and prioritize the activities of the operations and maintenance team.
From a development perspective, Vertech needed to create the tools to efficiently develop and commission this system as future solar sites are brought online. Vertech made full use of graphical templates, and also extended the Ignition UDT feature set in order to build powerful UDTs while maintaining the flexibility required in this application. Configuration screens and scripts were developed to simplify the instantiation and configuration of complex objects.
Result: Ignition enabled Vertech to provide a SCADA system for its customer — DEPCOM Power — which vastly improves upon the status quo in the industry. The customer now has more data available and the user interface is easier to use, allowing operations and maintenance teams to be more effective when identifying and troubleshooting issues. The analysis of site performance data, which used to be a manual task, is now automated so any site performance issues are quickly brought to the attention of the appropriate people.
The system can also be developed and commissioned in record time, allowing Vertech to meet schedules which would otherwise be impossible. With Ignition, Vertech can build a no-compromise solution, providing a better product with less development time.
For a typical site:
- 15,000 tags
- 30 screens
- 10 clients
- 10,000 alarms
- 100 devices
- Ignition Standard Architecture
- 1 Local MS SQL Database
- 1 Off-site MS SQL Database
- 2,000 tags historicized
Josh joined Vertech in 2013 after completing his Master’s degree in Mechanical Engineering at UCLA. As a senior control systems integrator, Josh leads the technical execution of integration projects in the energy, semiconductor, water/waste water, and mining markets. His expertise includes system-level design, PLC and SCADA system programming, and field startup and commissioning.Created By:
Vertech is a control systems integration firm providing world-class automation solutions for industrial clients. Vertech provides custom software tools to automate machinery and processes, inform and empower system operators, and to streamline business operations through real-time data analysis. The company’s programming skill sets including HMI/SCADA, PLC, SQL, .NET, and a variety of other languages combined with industrial networking, electrical design, UL-508a panel manufacturing, and field commissioning capability enable it to provide full-service integration from the plant floor to the board room.
Website: Vertech.comProject For:
DEPCOM Power’s Founding Team of ten members came together in 2013, bringing 225 years of conventional and renewable power industry experience, to build a best-in-class company solely based on PV Solar EPC/O&M, centered on team, shareholder & customer satisfaction. DEPCOM leverages a highly experienced team of solar industry veterans, the best module technology available, the most cost-efficient balance-of-system components, and the industry’s best-in-class execution practices to provide safe, high-quality, high-production, and cost-effective utility solar PV systems. The DEPCOM Power team has been awarded more than 15 projects, totaling more than 225MW.Industry:
Utility-Scale Solar Energy
