Eramosa Engineering Inc.
Connecting Numerous Systems for a Brighter Solar Future
Project For: Canadian Solar Solutions
This project was awarded an Ignition Gold Firebrand Award
- Approx. 500 analog tags and several thousand status/alarm tags per spoke
- 20 screens
- 20 clients in use, typically (designed for 100 clients)
- Ignition Hub & Spoke Architecture with cloud-hosted central gateway and historian
- More than 30 spokes (more planned for future)
This project involved working with Canadian Solar to create CSEye — a custom hybrid asset performance monitoring and computerized maintenance management system (CMMS) application for the solar photovoltaic (PV) operations & maintenance sector of the renewable power-generating market. CSEye is a comprehensive tool providing value to stakeholders at all levels of the Canadian Solar operations & maintenance group. Ignition provided a customizable application development environment providing full access to critical operational data from various existing SCADA architectures while allowing the project to scale as needs arose.
Problem: Canadian Solar had internally developed separate systems for performance monitoring, reporting, and maintenance management. As the company’s portfolio of projects expanded globally, it was clear that the tools pieced together under necessity would not suffice or scale to the satisfaction of the Canadian Solar operations & maintenance team. And a market-leading approach to monitoring required a change from a retrospective analysis to a near-real-time analysis.
Solution: Ignition solved the problem of disjointed legacy systems, providing a single application environment capable of:
- Cost-effective client licensing that would scale as needed
- Gateway architecture suitable for cloud hosting, allowing server and resource scaling throughout the product lifecycle
- Reliably feeding historical data from each spoke for near-real-time analysis
- Using gateway services and distributed tags for centralized alarming and alarm management
- Pulling historical and real-time data from various architectures including OPC-UA, Modbus, Ethernet IP, Siemens Ethernet, and RESTful web services
- Configuring/deploying a spoke using templated UDT tagging structures, thus allowing for cost-effective integration to the central gateway
- UDT tagging structures to provide tagging standardization at the central gateway
- Standard charting tools for performance monitoring while providing fully customizable Python scripting and database queries for development of the maintenance management system
Result: Building out the custom application within Ignition brought these benefits:
- A single web-launched application for performance monitoring and maintenance management
- A single application generating specific and relevant content for all users, including control room operators, data analysts, technicians, portfolio owners, and senior executives
- Ability to respond to performance deviations and reduce lost generating opportunities
- Ability to turn performance deviations and system alarms into actionable work orders with technician dispatch and resolution tracking
- Architecture suitable for future adaptation and enhancement
As the CSEye application is used across the various disciplines, continuous feedback is being generated. The application recently finished new development to bring in Japanese localization. The development team is undertaking the next phase of development focused on enhancing the tool for each user group. The user group utilizes Jira issue & project tracking for providing feedback and has identified 70 opportunities for improvement. The team expects to have this new development completed by October 2017.
Presented By: Clayton Balfour
Since joining Eramosa in 2013, Clayton has gained experience in the water, waste water, and renewable energy industries — specifically in the areas of SCADA, instrumentation & control, software integration, and data collection & reporting. He specializes in PLC & HMI development and integration and has played a significant role in implementing the SCADA systems for Canadian Solar’s newest 15 10MW solar farms. From design and development to site commissioning and acceptance testing, Clayton is dedicated to providing a top-quality product and exceptional service.Created By: Eramosa Engineering Inc.
